Pentair Dominator 5″ Well Pump – 140-65M Automatic

This product has now been discontinued. Get in touch with us and we can advise you on the best replacement for your use case.

Pentair Dominator 5″ stainless steel multistage well pump with float switch, 230v single-phase. Gives 63 m of head at 20 l/min and up to 140 l/min from a 1.1 kW motor, starting and stopping with the water level. 1¼” female outlet, 20 m cable, clean water only.

Free UK delivery
on orders over £200

Need advice?
01252 515169

SKU: 319-1070 Categories: ,

Description

The Pentair Dominator 5″ 140/65 M Automatic (code 319-1070) is a stainless steel multistage submersible pump with a float switch, built for higher flows from wells, tanks and clean watercourses. Its 1.1 kW motor and seven stages give 63 metres of head at 20 litres per minute, 49 metres at 60 l/min and 33 metres at 100 l/min, up to 140 l/min at 13 metres. It runs on 230v single-phase mains, draws 7.2 A and has a 1¼” female outlet.

The float switch runs the pump while there is water and stops it as the level drops, which makes it a good fit for filling a large tank from a well or emptying a storage tank. The Dominator 5″ 140/65 M is the same pump without the switch. For lighter duties, the Dominator 5″ 70/50 M Automatic offers the same float control with a 0.6 kW motor.

The pump body, suction screen, impellers, diffusers and shaft are AISI 304 stainless steel, and the mechanical seal is graphite against aluminium oxide, running in an oil chamber. The sealed dry motor is IP68 rated with Class F insulation, runs at 2850 rpm and is cooled by the water it pumps, with the capacitor and a thermal cut-out built in. Pentair rates it for continuous duty.

The 140/65 M Automatic shares its dimensions with the manual version: 550 mm long, 132 mm in diameter and 15.8 kg.

Features

  • Float switch starts and stops the pump with the water level
  • 63 m head at 20 l/min, 49 m at 60 l/min, up to 140 l/min
  • Seven stages, 1.1 kW motor, 230v single-phase, 7.2 A
  • AISI 304 stainless steel body, impellers, diffusers and shaft
  • IP68 motor with built-in capacitor and thermal protection
  • 1¼” female outlet, 20 metre power cable
  • 550 mm long, 132 mm diameter, 15.8 kg

Applications

  • Filling large storage or header tanks from a well
  • Emptying and transferring clean water between tanks
  • Garden and smallholding irrigation from a well or pond
  • Lifting water uphill over a long pipe run

For clean water only, up to 40°C, with no suspended solids or abrasive material, so it is not a drainage pump or a pump for sandy bores. At 132 mm across it is wider than a 5-inch (127 mm) borehole; for a 4-inch bore, see the Pentair Dominator 4″ well pumps. Pentair rates it for up to 17 metres below the water level. The float needs space to rise and fall, so this version suits open wells, tanks and sumps rather than a tight bore.

Pentair Dominator 5 inch 230v well pump performance curves, head against flow for the 70/50 and 140/65

The Pentair Dominator 5″ range

ModelControlMotor P2 (kW)Current (A)StagesHead at 20 l/min (m)Max flow (l/min)Length x Dia (mm)KgCode
Dominator 5″ 70/50 MManual0.64.064860475 x 13213.7319-1000
Dominator 5″ 70/50 M AutomaticFloat switch0.64.064860475 x 13213.7319-1010
Dominator 5″ 140/65 MManual1.17.2763140550 x 13215.8319-1060
Dominator 5″ 140/65 M AutomaticFloat switch1.17.2763140550 x 13215.8319-1070

All four models are 230v single-phase with a 1¼” female outlet and 20 m power cable. See the Pentair Dominator 5″ range page for help choosing a model and answers to common questions.
