Pentair Dominator 5" 230v Well Pumps
The Pentair Dominator 5″ well pump is a stainless steel multistage submersible pump for lifting clean water from wells, tanks, lakes and watercourses on standard 230v single-phase mains. It sits fully under the water, so there is no priming, and stacked impellers give it the pressure to supply a house, a garden irrigation system or a storage tank on higher ground.
The pump body, suction screen, impellers, diffusers and shaft are all AISI 304 stainless steel. The motor is a sealed, IP68 dry motor cooled by the water it pumps, with the capacitor and a thermal cut-out built into the motor, and every model comes with 20 metres of rubber-sheathed power cable. Each pump is 132 mm in diameter with a 1¼” female outlet.
Dominator 5″ 70/50: flow, head and switching
The two figures in the model name are a rough guide to flow in litres per minute and head in metres. On the 70/50, Pentair’s curve shows 48 metres of head at 20 l/min, falling to 17 metres at 60 l/min, from a 0.6 kW motor. It suits a single property or a modest watering system where pressure matters more than volume.
The higher-flow 140/65 has been discontinued, so the 70/50 is the Dominator 5″ we can now supply. If you need more flow than it gives, call us on 01252 515169 and we can suggest an alternative.
The M in Pentair’s naming means single-phase 230v. The 70/50 comes in a manual version, which runs whenever it has power and needs your own controls, and an automatic version with a float switch that starts and stops the pump with the water level.
Need something slimmer for a narrow bore? Look at the Matra Venus borehole pumps or the Pentax 3S 3-inch borehole pumps.
| Model | Control | Motor P2 (kW) | Current (A) | Head at 20 l/min (m) | Max flow (l/min) | Length (mm) | Weight (kg) |
|---|---|---|---|---|---|---|---|
| Dominator 5″ 70/50 M | Manual | 0.6 | 4.0 | 48 | 60 | 475 | 13.7 |
| Dominator 5″ 70/50 M Automatic | Float switch | 0.6 | 4.0 | 48 | 60 | 475 | 13.7 |
| Dominator 5″ 140/65 M (no longer available) | Manual | 1.1 | 7.2 | 63 | 140 | 550 | 15.8 |
| Dominator 5″ 140/65 M Automatic (no longer available) | Float switch | 1.1 | 7.2 | 63 | 140 | 550 | 15.8 |
All four models are 230v single-phase, 132 mm in diameter, with a 1¼” female outlet and 20 m cable. Click through to any model for its full performance figures.
Showing all 4 results
60 l/min · 47 m · 230v
Manual Pentair Dominator 5" stainless steel multistage well pump, 230v single-phase. Gives 48 m of head at 20 l/min ...Read More£541.78 +VAT
60 l/min · 47 m · 230v
Pentair Dominator 5" stainless steel multistage well pump with float switch, 230v single-phase. Gives 48 m of head at ...Read More£562.48 +VAT
140 l/min · 63 m · 230v
This product has now been discontinued. Get in touch with us and we can advise you on the best ...Read More140 l/min · 63 m · 230v
This product has now been discontinued. Get in touch with us and we can advise you on the best ...Read More
Where to Use Dominator 5″ Well Pumps
Pentair designs the Dominator 5″ for lifting clean water from traditional wells, feeding tanks that pressurise a domestic water system, small automatic garden irrigation and gravity-fed irrigation. In practice that means a dug or lined well on a rural property, a large rainwater or spring-fed storage tank, or a clean pond or stream used for watering.
Size the pump against the whole job, not just the depth of the water. Add the height from the water level to the highest outlet, the friction loss in the pipe, and the pressure you want at the tap or sprinkler (10 metres of head is roughly 1 bar), then read the flow from the curve. Our guide to pump head and flow rate walks through the sums, and how to select the right well and borehole pump covers the wider choice.
Know the limits before you buy. The Dominator 5″ is for clean water up to 40°C, with no suspended solids or abrasive material, so sandy bores and dirty water are out. At 132 mm across, the pump body is wider than a 5-inch (127 mm) borehole, despite the name. If your bore is 4 inches, the Matra Venus borehole pumps are the ones to look at; for a small garden tank, the lighter Well Buddy pumps may be enough. You can compare everything in our well and borehole pumps category.
Frequently Asked Questions
Will a Dominator 5″ pump fit in a 5-inch borehole?
No. The pump is 132 mm in diameter and a 5-inch bore is about 127 mm, so it will not go down. Pentair does not publish a minimum bore size, so measure the internal diameter of your well or casing, allow room for the cable and delivery pipe beside the pump, and call us if it is close.
What does the automatic version do?
The automatic models have a float switch. As the water rises the float lifts and starts the pump; as the level falls it drops and switches the pump off. The float needs room to move, so the automatic versions suit open wells, tanks and sumps rather than tight bores. The manual models have no switch and run whenever they have power, so you control them yourself or through separate controls.
Is the Dominator 5″ 70/50 right for a house supply?
It can feed a domestic system, usually by filling a tank or supplying a pressure vessel and pressure switch. It suits a single home with modest demand, giving 35 metres of head at 40 l/min. The higher-flow 140/65 has been discontinued, so if several outlets will run together or the water must travel a long way uphill, call us and we can suggest an alternative.
How deep can the pump be submerged?
Pentair rates the current Dominator 5″ for up to 17 metres below the water level. Lower it on its delivery pipe or a rope, never by the power cable, and keep it clear of any silt at the bottom of the well.
What is the Dominator 5″ made of?
The pump body, suction screen, impellers, diffusers and shaft are AISI 304 stainless steel. The mechanical seal is graphite against aluminium oxide, running in an oil chamber, and the motor is IP68 rated with Class F insulation and built-in thermal protection.
For help choosing between the manual and automatic versions, call the AES Rewinds team on 01252 515169 or email sales@aesrewinds.com. Tell us the depth to the water, the height to your highest outlet and the flow you need.
