GMP HGM Self Priming Cast Iron Dirty Water Pump – B2KQA EA3C 110v (HGM2)

Description

The GMP HGM-2 B2KQA EBBU 110v self priming dirty water pump (code 070-114) is an electric self priming surface pump in cast iron, for dirty water with solids. It pumps up to 390 litres per minute and reaches a maximum head of 16 metres from a 1.5 kW motor on 110v, the reduced-voltage supply used on UK construction sites through a site transformer. It is the 110v version of the HGM-2 for building sites running from a transformer, as a bare pump.

The GMP HGM-2 B2KQA 2757 is the same pump for 230v single-phase. The GMP HGM-2 B2KQA EBBU FR is mounted in a protective crash frame. The GMP HGM-2 B2KQA EBBU SAC is mounted on a sack truck for moving around site. The GMP HGM-3 B3KQA 1780 is the next size up, 850 l/min to 15 m.

The pump sits beside the water and lifts it from up to 6 metres below through the suction hose, so nothing electrical goes into the water. The casing and multi-blade impeller are cast iron, with a stainless steel shaft and carbon mechanical seal, and a non-return valve on the inlet keeps the casing full after it stops so it re-primes quickly.

Features

• Self priming from up to 6 m suction lift
• Up to 390 l/min and 16 m head
• 1.5 kW motor, 110v, 19 A
• 2″ inlet and outlet
• Solids up to 14 mm
• Cast iron casing, stainless steel shaft, carbon mechanical seal
• 22 kg

Applications

• Construction site and excavation dewatering
• Flood clearance and basement pump out
• Irrigation and water transfer
• Hire fleets

Suitable for clean and dirty water with solids. Not designed for flammable liquids, oils or chemicals.

The GMP HGM Self Priming range

Flow and head are the manufacturer’s published maximums. See the GMP HGM Self Priming range page for help choosing between models and answers to common questions.
